3000rpm BLDC Electric Motor PV 57mm stepper motor

3000rpm Bldc Motor 57mm Dia Brushless Dc Motor

The BLDC motor efficiency over that of a traditional brushed motor is another benefit to using a brushless motor. Brushless motors have an overall higher speed and torque, and produce less noise than traditional brushed motors. They also run more efficiently and have little or no power loss, which is a problem that can accompany brushed motors due to increased friction caused by the brushes. BLDC motors have reportedly hit 85 to 90 percent efficiency margins, which is higher than the standard brushed motors at 75 to 80 percent.

Brushless DC motors must also be electronically commutated, which means the motor is regulated by a control mechanism. That feature allows the 3 phase BLDC motor to change speeds at varying degrees along with the ability to quickly accelerate and decelerate to provide for the most efficient use of power and productivity when it comes to output. BLDC motors also typically weigh less than a brushed motor, but they have the ability to provide similar power outputs. With the capability to provide high speed performance and efficient operation, the brushless DC motor is an obvious choice that can be used in multiple applications across a range of industries, including:

Heating, Ventilation and Air Conditioning
Electrical vehicles
Pumps
Laboratory equipment

Product Description

1. Three phase BLDC motor;

2. Made of anti-high temperature permanent magnet and high quality cold-rolled steel sheet;

3. CNC machine engraved axle, high quality bearing;

4. Alluminium alloy cap, plastic insulation, copper wires auto-wired.

5. Featured by its low noise, low vibration, low heating, of stable performance;

6. Excellent internal damping, can be used by different industries and under any circumstances, long lifespan.

Date Sheet

Number of Poles	4
Number of Phases	3
Nominal Voltage VDC	24
Rated speed RPM	2500	3000	3000	3000	3000	3000
Continuous Torque N-m	0.057	0.11	0.165	0.22	0.33	0.44
Output Power Watts	15	34	52	69	103	138
Peak Torque1 N-m	0.18	0.38	0.58	0.8	1.2	1.6
Peak Current Amps	2.7	6.8	10.0	13.2	19.8	25.8
Line to line Resistance Ohms	3.6	1.2	0.9	0.65	0.5	0.35
Line to line Inductance mH	2.6	2.2	1.3	1.1	0.6	0.5
Torque constant N-m/Amps	0.074	0.059	0.06	0.062	0.062	0.063
Back EMF V/kRPM	7.75	6.2	6.3	6.5	6.5	6.6
Rotor inertia g·cm2	32	42	58	72	106	140
Body Length (L) mm	37	47	57	67	87	107
Mass kg	0.43	0.5	0.67	0.75	1.0	1.25
