3 Phase DC Motor Electrical Brushless 4000 Rpm 36V 23W With CE ROHS

Product Categories

Changzhou Prevail Motors and Electrical Equipment Co., Ltd

Contact Now

Add to Cart

3 Phase Dc Motor Electrical Brushless Dc Motor 4000 Rpm 36V 23W With CE ROHS

	Model
Number Of Phase	Phase	3
Number Of Poles	Poles	4
Rated Voltage	VDC	36
Rated Speed	Rpm	4000
Rated Torque	N.m	0.055	0.11
Rated Current	Amps	1.2	2
Rated Power	W	23	46
Peak Torque	N.m	0.16	0.33
Peak Current	Amps	3.5	6.8
Back E.M.F	V/Krpm	7.8	7.7
Torque Constant	N.m/A	0.074	0.073
Rotor Inertia	g.c㎡	30	75
Body Length	mm	37	47
Weight	Kg	0.33	0.44
Sensor	Honeywell
Insulation Class	B
Degree of Protection	IP30
Storage Temperature	-25～+70℃
Operating Temperature	-15～+50℃
Working Humidity	85% or under 85% RH(non condensing)
Working Environment	outdoor(no direct sunlight),Non-corrosive Gas, Non-inflammable gas, No oil fog, No dust
Altitude	1000m or under 1000m

Product Description

1. Three phase BLDC motor;

2. Made of anti-high temperature permanent magnet and high quality cold-rolled steel sheet;

3. CNC machine engraved axle, high quality bearing;

4. Alluminium alloy cap, plastic insulation, copper wires auto-wired.

5. Featured by its low noise, low vibration, low heating, of stable performance;

6. Excellent internal damping, can be used by different industries and under any circumstances, long lifespan.

main applications of bldc motor

Industry	Content	Industry	Content
Medical equipment	Hand-held surgical instruments	Aerospace Industry	Electric seat adjustment post

	Surgical robot		Flight recorders

	Micro-injection pump; Peristaltic pump		Autopilot

	Dialyzer		Air-conditioning system

	Automatic dosing system		Space Robot

	Radiation therapy equipment

	Diagnostic equipment and testing instruments
Robot	Humanoid robot	Auto industry	Adjustable shock absorbers

	Service robots		Emission abatement system

	Teaching Robots		Electronic steering

			Electronic tachometer
Industrial Automation	Precision Positioning System	Communications Equipment	Antenna System

	Handling System		Copier / printer / plotter
