    Nema 34 High Torque Stepper Motor Planetary Gearbox

    Nema 34 Planetary Gearbox High Torque Stepper Motor With Gearbox


    They move in steps based on pulses sent to the stator windings, thus they do not have a horsepower rating because they do not actually rotate continuously. The speed of the motor is controlled by the frequency of the pulses. The stepper motor is used for precise positioning with a motor, such as hard disk drives, robotics, antennas, telescopes, and some toys. Stepper motors cannot run at high speeds, but have a high holding torque. A stepper motor can be thought of as a "digital" version of electric motor, because it converts digital pulses into fixed steps such that a computer system can easily "step" the rotation of the motor for precise control. A stepper motor is low cost, has simple drive electronics, is accurate, has a decent holding torque, and operates at moderate speeds. High acceleration and heavy loads that still require accuracy need a servo motor, the predecessor of the stepper motor.

    Step AngleMotor Length

    Current

    /Phase

    Resistance

    /Phase

    Inductance

    /Phase

    Holding Torque# of LeadsDetent TorqueRotor InertiaMass
    ( °)(L)mmAΩmHN.mNo.Kg.cm

    g.cm^2


    Kg
    1.8683.01.27.13.540.810001.7
    1.8682.81.43.92.480.810001.7
    1.8785.50.4644.641.214002.3
    1.8784.20.753.44.681.214002.3
    1.81156.00.66.58.742.427003.8
    1.81154.20.968.782.427003.8
    1.81556.20.75912.243.640005.4
    1.81554.21.25812.283.64000

    5.4


    Step AngleMotor Length

    Current

    /Phase

    Resistance

    /Phase

    Inductance

    /Phase

    Holding Torque# of LeadsDetent TorqueRotor InertiaMass
    ( °)(L)mmAΩmHkg.cmNo.g.cmg.cmKg
    1.8601.736.27.342801020.5

    Reduction ratio3.715.1813.7619.226.8517199.5139
    Number of gear trains123
    Length(L2) mm27.33542.7
    Max.rated torque kg.cm203040
    Short time permissible torque kg.cm406080
    Weight g350450550

    1. Using Enameled Copper Wire, Not Enamelled Aluminium Wire, So the motor is more reliable and long lifetime.
    2. Low noise, Long lifetime.
    3. More stable and safer when driving.


    Company Introduction
    Changzhou paliwei Motor Co., Ltd was a high technology industry zone in changzhou, china. Our products used in many kinds of machines, such as 3d printer CNC machine, medical equipment, weaving printing equipments and so on.

    Company spirit of sincere and good reputation, won the recognition and support of the broad masses of customers, at the same time with the domestic and foreign suppliers close community of interests, the company entered the stage of stage of benign development, laying a solid foundation for the strategic goal of realizing only really the sustainable development of the company.

    Q: How to order?
    A: send us inquiry → receive our quotation → negotiate details → confirm the sample → sign contract/deposit → mass production →cargo ready → balance/delivery → further cooperation


    Q: How about Sample order?
    A: Sample is available for you. please contact us for details. Once we charge you sample fee, please feel easy, it would be refund
    when you place formal order.


    Q: Which shipping way is available?
    A: DHL, UPS, FedEx, TNT, EMS, China Post,Sea are available. The other shipping ways are also available, please contact us if you
    need ship by the other shipping way.


    Q: How long is the deliver[Producing] and shipping?
    A: Deliver time depends on the quantity you order. usually it takes 15-25 working days.


    Q: My package has missing products. What can I do?
    A: Please contact our support team and we will confirm your order with the package contents.We apologize for any inconveniences.


    Q: How to confirm the payment?
    A: We accept payment by T/T, PayPal, the other payment ways also could be accepted,Please contact us before you pay by the other payment ways. Also 30-50% deposit is available, the balance money should be paid before shipping.
